SPECS
Technical Summary
Frequency Range (-10 dB)
73 Hz - 15 kHz
Nominal Coverage Pattern (H x V)
120° H x 60° V
Long-Term Power Handling
Bose extended-lifecycle test⁴: 120 W
AES transducer test⁵: 150 W
Power Handling, Peak
Bose extended-lifecycle test⁴: 480 W
AES transducer test⁵: 600 W
Sensitivity (SPL / 1 W @ 1 m)
91 dB SPL
Calculated Maximum SPL @ 1 m
Bose extended-lifecycle test⁴: 112 dB
AES transducer test⁵: 113 dB
Calculated Maximum SPL @ 1 m, peak
Bose extended-lifecycle test⁴: 118 dB
AES transducer test⁵: 119 dB
Nominal Impedance
8 Ω
TECHNICAL INFO
